2026 JLG ES2646
Get in Touch
Description
2026 JLG ES2646
Maximize productivity with the JLG ES2646, featuring a class-leading 1,200-lb. capacity for both indoor and outdoor work. This machine delivers double the battery life compared to a competitive model under similar test conditions, so you can run longer on a single charge.
Features May Include:
- The 1200-lb indoor and outdoor platform capacity beats the competition.
- Refreshed design delivers electric drive, for up to double the battery life of a standard scissor.
- Work in sensitive areas with optional CleanGuard leak containment system.
- Features a standard USB charger and phone holster, improving the operator experience while delivering a high degree of commonality with other JLG® scissors to simplify service.
STANDARD FEATURES
- 27 amp Multi-Function Universal Charger
- AC Receptacle in Platform
- Active Pothole Protection System
- All Motion Alarm
- Analyzer Port for Diagnostics
- Battery Condition Indicator
- CAN-Enabled Charger
- ClearSky Smart Fleet™ Hardware (CS550)
- Diamond Tread Steel Deck
- Dynamic Braking
- Electric Drive
- Foot-Actuated Deck Extension
- Fork Lift Pockets
- Greaseless Kingpin Joints
- Horn
- Hourmeter
- Lanyard Attach Points
- LED Motion/Amber Beacon (CS550)
- Lifting and Tie Down Points
- Load Sensing System
- Lubrication Free Scissor Arm Bushings
- Manual Descent Cable
- Movable, Removable Platform Control
- Nickel Plated Pins
- Proportional Controls
- QuikFold Rails
- Removable Ladder
- Scissor Maintenance Prop
- Self-Closing Gate
- Steel Swing-Out Doors
- Tilt Alarm and Light
- USB Charger & Phone Holder
- Variable Tilt
ACCESSORIES & OPTIONS
- 4 x 6V AGM Batteries, 220 ah
- 00W Inverter
- Anti-Vandalism Package
- CleanGuard® Leak Containment System
- Coiled Platform Control Box Cable
- Drive Motor Covers
- Dual Flashing Amber Beacons - LED
- Lithium Battery (1)
- Lithium+ Batteries (2)
- MDI (Ground)
- Panel Carrier
- Pipe Racks
- SkySense® Enhanced Detection System
- White Noise Alarm
Info
Industry
Agriculture
Make
JLG
Model
ES2646
Trim
Base
Year
2026
MSRP
N/A
Category
Agriculture Equipment
Subcategory
Miscellaneous Equipment
Specs
Height
Platform (Elevated): 26 ft (7.92 m) | Maximum Drive: Fully Elevated | Platform (Lowered): 45 in (1.14 m) | Platform Railing: 44.6 in (1.13 m) | Machine (Rails Raised): 89.6 in (2.28 m) | Machine (Rails Lowered): 71.7 in (1.82 m)
Load Capacity
Platform:1,200 lb (545 kg)
Fuel Type
Gas
Weight
5,295 lb (2,401 kg)
Drivetrain
Speed (Lowered): 3 mph (4.8 km/h) | Speed (Raised): 0.5 mph (0.8 km/h) | 24V AC
Turning Radius
Inside: Zero | Outside: 88 in (2.2 m)
Battery
4 x 6V 220 amp-hr
Tires
Standard: 16 x 5 in (406 x 125 mm)
Brakes
Multi-Disc Friction
Fuel Capacity
Hydraulic: 1.7 gal (6.4 L)
Width
Platform: 41.6 in (1.1 m) | Machine: 46 in (117 cm)
Length
Platform: 84 in (2.1 m) | Machine: 94.3 in (2.4 m)
Wheelbase
74 in (1.9 m)
Ground Clearance
3.9 in (9.8 cm)
